| Golf Cart LiFePO4 Battery (OEM/ODM) | |||||
|---|---|---|---|---|---|
| Datasheet | Rated Voltage | Rated Capacity | Rated Energy | Size/Custom | Weight |
| 36V (Support Customized Capacity/Size) | |||||
| 36V 100Ah | 38.4V | 100Ah | 3840Wh | 430*350*180mm | ≈37kg |
| 36V 105Ah | 38.4V | 105Ah | 4032Wh | 425*210*245mm | ≈37kg |
| 36V 150Ah | 38.4V | 150Ah | 5760Wh | 460*380*220mm | ≈55kg |
| 36V 200Ah | 38.4V | 200Ah | 7680Wh | 540*380*240mm | ≈74kg |
| 48V (Support Customized Capacity/Size) | |||||
| 48V 100Ah | 51.2V | 100Ah | 5120Wh | 530*350*180mm | ≈46kg |
| 48V 135Ah | 51.2V | 135Ah | 6912Wh | 530*290*240mm | ≈61kg |
| 48V 150Ah | 51.2V | 150Ah | 7680Wh | 570*380*220mm | ≈68kg |
| 48V 200Ah | 51.2V | 200Ah | 10240Wh | 650*380*240mm | ≈92kg |
| 72V (Support Customized Capacity/Size) | |||||
| 72V 50Ah | 76.8V | 50Ah | 3840Wh | 470*330*150mm | ≈50kg |
| 72V 100Ah | 76.8V | 100Ah | 7680Wh | 730*350*150mm | ≈65kg |
| General | |||||
| Life Cycles | ≥6000 cycles (80%DOD), at 25°C | ||||
| Charge Temperature | 0 ~ 45°C (32 ~ 113°F) | ||||
| Discharge Temperature | -20 ~ 55°C(-4 ~ 131F) | ||||
| Storage Temperature | -10 ~ 45°C(14 ~ 113°F) | ||||
| Communication Mod | Vehicle CAN/Charge CAN/Intranet CAN/485 communication/Wireless communication | ||||
| Notes | Product size and weight are reference values, not the final product size and weight | ||||
Since 2013, CXJPowers has focused on the R&D of portable power stations, home battery storage powers, C&I energy storage, LiFePO4 battery pack, LiPo batteries, jump starters, solar power banks etc. energy storage products. It is a National High-tech Enterprise integrating R&D, production, sales and service.
CXJPowers factory is located in Chuangxinjia Industrial Park, No. 26, Xinglong Street, Tangxia, Dongguan, China, with 37 R&D engineers, 126 technicians, 85 sales team and 19,300m² office area & production base.
